Product type: CompactLogix controller
Product Series: 5370 L2 controller
Manufacturer Rockwell Automation/Allen-Bradley
Shipping weight 3 kg
Shipping dimensions 11 x 8 x 6 inches
Series A and B
The 1769-L27ERM-QBFC1B is a CompactLogix 5370 L2 controller designed and manufactured by Allen Bradley, a division of Rockwell Automation. The 1769-L27ERM-QBFC1B has a built-in power supply with a capacity of up to 24 volts DC. It also features two (2) EtherNet/IP ports and supports both linear and ring topologies. The compact 5370 L2 controller is designed to provide a scalable controller solution. This is suitable for a variety of applications and offers a variety of advanced features. The 1769-L27ERM-QBFC1B is equipped with two Ethernet ports and one USB port. The 1769-L27ERM-QBFC1B is designed to meet the growing needs of the user environment with a native expansion module. As a result, the unit ensures high performance and has a compact and affordable packaging. It is designed to reduce the required panel space for users by 40% and has advanced features to ensure high performance while maintaining a cost efficient module.
Devices under this family also have similar network protocol and information capabilities. This provides a common development environment for all control rules.
The 1769-L27ERM-QBFC1B provides users with support for integrated motion on EtherNet/IP. It also supports device-level ring network topologies and comes with built-in energy storage, eliminating the need for lithium batteries. For improved data integrity, the 1769-L27ERM-QBFC1B features a removable 1GB secure digital card. It has high-resolution simulation capabilities and supports thermocouple and even RTD inputs. The 1769-L27ERM-QBFC1B supports up to 32 controller tasks and up to 100 tasks. The 1769-L27ERM-QBFC1B has up to 4 local expansion modules with 16 digital inputs or 16 digital outputs and up to 4 universal analog inputs. For the addition of communication modules, the 1769-L27ERM-QBFC1B has a DeviceNet with 1769-SDN or a third party. The 1769-L27ERM-QBFC1B supports flash memory cards, using industrial-grade and certified secure digital memory cards.
