Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number Model 1756-L72K
Series ControlLogix
Module Type Processor module
I-O memory 0.98 megabytes
Features:
The 1756-L72K serves as the central processing unit (CPU) of the ControlLogix system. It performs control procedures, communicates with other devices, and manages I/O(input/output) operations.
Specifications:
Processor: Information about the specific processor types used in the 1756-L72K is not publicly available from Rockwell Automation.
Memory: It has 4 MB of user memory for storing program instructions and data. This capability allows for moderately complex control procedures.
Communication: The 1756-L72K May have a built-in communication port (possibly USB or Ethernet) for connecting programming terminals, human machine interfaces (Hmis), and other devices.
I/O processing: It can handle large amounts of discrete and/or analog I/O, depending on the specific configuration of the I/O module. Rockwell Automation has specified a maximum of 128,000 digital I/ OS for the 1756-L62x series, including the 1756-L72K.
