1756-PA72K AC power module Open housing

Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number Model 1756-PA72K
Series ControlLogix
Module Type AC power module
Input voltage 120-240 volts AC
The 1756-PA72K module is a ControlLogix AC power module with an AC voltage range of 85 to 265 V. The 1756-PA72K module has a nominal input voltage of 120 to 240 volts AC. The module supports 47 to 63 Hz line frequencies. The maximum rated input power is 100 VA or 100 W. The module has a maximum power output of 75 watts and a temperature of 32 to 140 degrees Fahrenheit. The maximum inrush current is 20 amps. The holding time is 85 cycles for 5 volts AC, 6 cycles for 120 volts AC, 6 cycles for 200 volts AC, and 6 cycles for 240 volts AC. The 1756-PA72K module has a current capacity of 1.5 volts DC 1.2 amps, 3.3 volts DC 4 amps, 5.1 volts DC 10 amps, and 2.8 volts DC 24 amps.

The 1756-PA72K module weighs about 0.95 kg. Modules measure 5.51 x 4.41 x 5.71 inches. The module is installed on the left side of the 1756 chassis. Chassis compatible with the 1756-PA72K module include 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17 chassis (Series A, B, and C). The recommended wire diameter for the 1756-PA72K module is 14 AWG. Wires should be solid or stranded copper with a temperature rating of 194 degrees Fahrenheit or higher. The maximum insulation of the wire should be 3/64 inch. The type of cable for the power port is 1. Conductor screw torque should be 5 pounds per inch. The 1756-PA72K module has an open housing and complies with the T4 North American temperature specification. The 1756-PA72K module has a storage and operating temperature range of -40 to 185 and 32 to 140 degrees Fahrenheit, respectively.
