Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number 1756-TBS6H Series
Series ControlLogix
Module type Wiring terminal
The Allen-Bradley 1756-TBS6H is a detachable terminal (RTB) for the 1756 I/O module. It is an I/O module attachment that must be ordered separately. It provides flexibility for interconnecting 1756 I/O modules and industrial plant cabling. It plugs easily into the front of the I/O module.
The 1756-TBS6H detachable terminal is A 36-pin spring clamp with a standard housing (arm depth < 2.5 A €- mma €- ^2). It measures 5.51 x 4.41 x 5.71 inches. It weighs 0.3 pounds. For wiring, use 0.33-2.1 μ-mma €- ^2 (22-14 AWG) solid or stranded copper wire with a temperature rating of 90 °C (194 °F) or higher and a maximum insulation specification of 1.2 mm (3/64 in). Do not use more than one conductor on any single terminal.
Each ControlLogix I/O module is installed in any ControlLogix chassis and requires a removable terminal (RTB) to connect all field side wiring. Each I/O module has many applications, from high-speed digital processing to process control. In the ControlLogix architecture, input and output states are shared between multiple controllers in the same or different chassis using producer-consumer technology. The 1756-TBS6H RTB is suitable for clean and dry industrial environments with an operating temperature of 0-60 °C and an operating impact of 30g.
