Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog number 1769-Bourn
Product line CompactLogix
Module Type Boolean control module
Allen-Bradley 1769-BOOLEAN with LED display and open housing. It has a depth of 3.34 inches, a height of 4.65 inches, a width of 1.38 inches, and a weight of approximately 0.625 pounds. It has a 10-30V DC input signal and a 20.4-26.4V DC output signal. It has a closed loop time of 1 microsecond and can be mounted on a DIN rail or panel mount. 1769-BOOLEAN Module is a combination of 24V DC input/output. Its output can be controlled using Boolean expressions or directly from the program. When the expression is TRUE, it represents the output as an ON state. When it is FALSE, the output channel is OFF. The module's Boolean expression has four operations to configure, OR, AND, XOR, or NONE.
1769-BOOLEAN Module has 8 single-ended 24V DC inputs and 4 single-ended 24V DC power outputs. The source describes how current flows through I/O and field devices. It has a maximum current consumption of 220mA at 5.1V and 0mA at 24V. The maximum heat dissipation power can reach 3.55W. 1769-BOOLEAN has an isolation voltage of 75V DC and can withstand 1200V AC for 1 second or 1697V DC for 1 second in dielectric tests. Its isolation voltage is IEC certified Class 2 enhanced insulation type.
1769-BOOLEAN equipped with 8 virtual and real inputs and 24V AC feed current. The module operates in a voltage range of 10-30 V DC (30 °C) and 10-26V DC (60 °C). It has 10 μs turn-on and turn-off input delays with input impediments of 2.0 kΩ (24V DC) and 2.3 kΩ (30V DC).
