The 1769-CLL1 is a 1-foot left-to-left bus extension cable manufactured by Allen-Bradley, a brand of Rockwell Automation. It is specifically designed for the Allen-Bradley CompactLogix 5000 Programmable Automation Controller (pac).
Here is a breakdown of its main features and functions:
Function: Extend the communication bus between CompactLogix controllers or I/O modules.
Left-to-left configuration: Connect the left port of one device to the left port of another device. This is useful for creating a linear topological network or for connecting multiple devices together.
Length :1 ft (0.3 m)
Applications:
Industrial automation systems use CompactLogix controllers.
Extend the range of the communication bus between controllers or I/O modules.
Create a Daisy chain network connecting multiple devices.
Benefits:
Flexible placement of controllers and I/O modules in the control cabinet or system.
Simplify system wiring by using standardized communication buses.
Contributes to modular and scalable control system architecture.
