Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number 1769-CRL1
Product line CompactLogix
Module type Expansion cable
The 1769-CRL1 right-to-left cable is a product of Allen-Bradley/Rockwell Automation and is part of the CompactLogix and MicroLogix 1500 product families. This module type of expansion cable has a right-to-left connection with a length of 1 foot or 305 mm and an isolation voltage of 30 volts or 30 volts continuous. It also has a backplane current of 24 amps at 1.4 volts, a power consumption of 33.6 watts and a power consumption of 7.5 watts. It is compact, weighs just 0.66 pounds and can operate at temperatures ranging from 32 to 140 degrees Fahrenheit. Allen-Bradley 1769-CRL1 CompactLogix Right to left cables are of an open housing type with end caps. This cable can be part of Series A or Series B. Typically, these CompactLogix cables feature a standard control engine with a typical development setup, helping to provide control for mid-range applications in an easy-to-use industrial environment.
The 1769 CompactLogix cable, like the 1769-CRL1 right-to-left cable, is easy to use in small to medium-sized control applications that do not require safety or motion features. They also feature a 1769-SDN communication interface module that helps provide I/O control over the DeviceNet network as well as remote configuration of the device.
