Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number 1769-CRL3
Product line CompactLogix
Module type Expansion cable
Allen-Bradley 1769-CRL3 is a compact I/O cable for the DriveLogix 5730 controller. 1769-CRL3 is not a module or power supply, but a cable that connects a group or module group. It is a right-to-left bank extension cable type that extends the bus communication line. The 1769 system can only use a maximum of 2 cables, allowing 3 sets of I/O modules to use their own power supply. The 1769-CRL3 measures 3.28 feet and is typically used in base unit systems with compact I/O and Bank 1 horizontal/vertical orientation. The system requires right-to-left expansion cables to extend the 1769 I/O system to more than 1 power supply. The 1769-CRL3 cable provides configuration flexibility with horizontal and vertical system expansions.
The 1769-CRL3's 3-foot cable weighs about 350 grams, and the 1-foot cable weighs about 300 grams. It has a storage temperature of -40-85°C, an operating temperature of 0-60°C, a relative humidity of 5-95%, and no condensation. The 1769-CRL3 cable operates at a height of 6,561 feet. Its operating vibration is 10-500 Hz, 5G, with a maximum peak-to-peak value of 0.030 inches. Its general relay operation is 2G, 7.5G when panel mounted, and 5G when DIN rail mounted. The working impact is 30G when the panel is installed, 20G when the DIN rail is installed, 40G when the panel is installed, and 30G when the DIN rail is installed.
