Manufacturer: Honeywell
Product Number :8C-PAINA1 51454470-175
Condition: New & available
Product type: Analog input module
Origin: USA
Price: USD1500.00
Payment: Wire transfer, Western Union
Dimensions: 152 x 89 x 30 mm
Weight: 0.45 kg
Approved: CE, UL
Guarantee: 12 months
Overview:
The Honeywell 8C-PAINA1 is an analog input module for Experion PKS control systems. It is a single-ended coated module with 16 channels. Here are some of its key technical specifications:
Input type: Current (2-wire or self-powered transmitter)
Input range: -10 to +10 mA, 0 to 20 mA, 4 to 20 mA
Resolution: 12 bits
Accuracy: ±0.1% of the range
Common mode rejection: 80 dB (50/60 Hz)
Power Supply: 24 VDC
Power consumption: 100 mA (typical value)
