Brand: FOXBORO
Model: FBM216 P0917XQ
Product type: Communication redundant input interface module
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Supported version: HART protocol v6
Interface: Eight group isolation channels
Communication with the device: point-to-point, master/slave, asynchronous, half-duplex, baud rate of 1200
Error checking: Parity check for each byte and a CRC check byte
Speed: 2 messages per second
The fastest ECB blocking period allowed: 500 ms
Maximum distance (FBM216 to field equipment) : Compliant with HART FSK Physical Layer Specification HCF_SPEC-54, Revision 8.1 [Up to 3030 m (10,000 ft)]
Compliance voltage: 18 V DC (minimum, 20.5 mA)
These standard 200 Series baseboards support distributed control of small and large systems, in particular the following Foxboro Evo™ system modules:
1. The field control processor 270 (FCP270) is fault tolerant or non-fault tolerant
2. FCM such as field communication modules (FCM100Et and FCM100E)
3. Fieldbus expansion module (FEM100E)
4. Fieldbus isolator/Filter module (FBI100)
5. Standard Fieldbus module (FBM) and 100 series FBM connection.
The 200 Series substrate supporting standard FBM enables the installation of the entire system by providing 2, 4, 8 FBM position unit increments and a combination of vertical and horizontal mounting
