IC693BEM341 Programmable logic controller Channel 2 Enables transmission

The IC693BEM341 is a FIP bus controller module belonging to the 90-30 series Programmable Logic Controller (PAC) family, previously owned by GE Fanuc   Manufactured by Automation, now part of Emerson Automation. The module comes with two (2) 9-pin D-shell connectors, Factory Instrumentation Protocol (FIP) support for 2.5MHz data rate and an RS485 communication port for firmware upgrades. The module can be used to connect to the 90-70 series through the configuration of the DIP switch. It features four (4) LED status indicators, such as a CD1 / CD2 carrier detector LED and an LED that supports TEN1 / TEN2 transmission.
The IC693BEM341 is a Factory Instrumentation Protocol (FIP) compatible module that belongs to Emerson Automation's Series 90-30 Programmable Logic controller (PLC) family and was previously manufactured by GE Fanuc Automation. This module is an upgrade over the previous bus controller, as the IC693BEM341 has a data rate of 2.5 MHz. The IC693BEM341 specifically comes with three (3) built-in communication interfaces, two (2) 9-pin D-housing FIP bus connectors, and one (1) RS485 communication interface for software upgrades via firmware modifications. The module is also equipped with six (6) LED status indicators, such as channel 1 module normal, operation, carrier detection; Carrier detection of channel 2; Channel 1 enables transmission and channel 2 enables transmission. The FIB bus controller module is designed to connect to various devices, such as 90-70 series PLCS, via the FIB bus to FIP bus interface; Field control station via field control I/O module via field bus interface unit (BIU); Remote I/O The FIP remote I/O scanner module and common devices using the FIP interface module are disconnected. The IC693BEM341 requires a 90-30 series CPU with version 8.0 or later. For configuration, the module needs to download the valid configuration to the module using a handheld programmer (HHP), Windows programming software IC641CTLxxx Release 2.0 or later, or the FBCLOAD configuration utility. Additional features of the module include the ability to display firmware versions, time stamps of up to 1024 Booleans, and mode 30, including redundancy, slave I/O device management, time stamps, message services, MIPS synchronous exchange, and reception of external configurations.

The IC693BEM341 controller is a FIP bus controller designed and manufactured by GE Fanuc. This part belongs to the GE series 90-30. This particular controller model is an upgrade over the old bus controller and it includes different innovative features. When comparing this model with older models such as the GE 340 controller, they are functionally identical except for the increased network speed in the new IC693BEM341 model. The GE Fanuc IC693BEM341 FIP bus controller is a 2.5 MHZ version of the bus controller. It is also available with firmware version 3.01. This bus controller requires any IC693 PLC CPU version 8.10 or later. Another configuration requirement for this fieldbus controller is that it requires a handheld programmer or HHP. This HHP has programming software developed by Windows and it should be version 2.0 or later. The FBCLOAD configuration utility must be used to configure the controller to function properly on the network.
