Model: PP886 3BSE092980R1
Category: Touch panel
Finish: New, not new
Warranty: One year
Stock: Yes
Brand: ABB
Basic information
dimension
Weight 4.1 kg
Dimensions W x H x D (mm) 410 x 286 x 73 mm
Opening size W x H (mm) 394 x 270 mm
Installation depth mm. (including clearance) 66 (166) mm
Mounting panel mounting
Display type: Touch
Display size :15.4"
Brightness; 450 Kandar/m2
Display resolution, ratio 1280 x 800 pixels
Processor: ARM9 (800 MHZ)
Main memory: 1 gigabyte
External storage media; 1 x SD card slot (or SDHC loaded with the latest image)
Dimensions: WxHxD (mm) 410 x 286 x 73 mm
Power Supply :24 VDC (18 to 32 VDC)
Operating temperature; -30 °C to +70 °C
The touchscreen panel features gorgeous TFT/LED display colors and multi-protocol connectivity. The rugged Panel 800 series includes PP886R, PP887H, PP887H-CFC and PP887S, which are easy to use Hmis with comprehensive and integrated templates and libraries for every possible process you need. All rugged panels are equipped with high-resolution graphics for TFT/LED displays. Most models offer wide screens and high-resolution displays for increased efficiency and excellent operator interaction.
Characteristics and advantages
Easy to use
A fully deployable human-machine interface with comprehensive and integrated templates and libraries for every possible process. The Panel Builder tool features the familiar Microsoft® Windows® environment and multiple language support for fast, simple, and efficient engineering.
State-of-the-art graphics
Vector-based high resolution graphics with TFL/LED display with icon-based interface, navigation and control.
Solid and reliable
The Panel 800 is made with a robust and lightweight die-cast powder-coated aluminum housing. The front housing can withstand wet, dusty and harsh environments. The operating temperature ranges from -30° C to + 70° C with a maximum humidity of 95%.
A truly open platform
These panels are built on the open architecture and technology that comes with the.NET framework, enabling multi-brand controller connectivity. There are a variety of connection options available for local communication, extension, remote access, and more.
Try it out before you use the app
Applications can be simulated and run directly from Panel Builder 800 before use.
