Model: PXIe-6345
Number of analog output channels: 64
Analog output resolution: 16 bits
Maximum update rate: 1 MS/s
Analog output voltage range: -10 V to 10 V
Bus connector: PXI Express
16-bit, 64-channel, 1MS/sPXI analog output module
The PXle-6739 is a high density analog output module. The device is ideal for applications such as high density excitation-response testing and open loop simulation. You can use up to 16 channels, each in a different group, to achieve maximum sampling rates. The PXle-6739 also includes 20 digital I0 lines, 4 counters/timers, digital triggers and advanced timing to meet a variety of application needs. The module's digital triggering and PXIe synchronization capabilities enable it to be coupled to more data acquisition motion and visual products, helping users build highly customized measurement solutions to test innovative designs.
